Through serious and deep research, LAUDIO PRO proudly introduces the LA Series Line Array System. The advanced technologies are widely applied together with special optimization technique results in an excellent performance and high efficiency.  To design an array system requires perfect grasp of sophisticated directivity analysis and radiation control. It needs also an overall predict and accurate measurement of standing waves, resonance and vibrations of speakers and the metal facilities. Even it’s quite challenging, LAUDIO engineers know it fairly well.

Applications:
Large and Medium scale venues including stadium, concert hall, auditorium, theatre, clubs, touring show, rental market etc.

Frequency Response      25Hz－450Hz

Power handling              1500W (RMS) 6000W (PEAK)

Sensitivity                       110dB(1W@1M)

Max@S.P.L.                     140dB(PEAK/1M)

LF section                        21" woofer

Nominal impedance       8 ohm

Speaker cables               1(+)1(-)

Input connectors            2×NL4MP speakon

Dimensions                     582×886×852mm

Enclosure                         Birchwood

Net weight                      58kg

Gross weight                   65kg
