PC Control， Andriod APP Control Optional

WiFi wireless control Optional
Bluetooth connectivity available
Professional Karaoke Effects

1) Optical digital input and two analog inputs, input gain can be set independently.

2) The microphone is divided into two groups of AB, and all functions can be debugged individually or simultaneously.

3) Music is divided into left and right channels, and all functions can be debugged separately or simultaneously.

4) All input and output channels are equipped with high-pass and low-pass filters, multiple filtering types are available for selection and customization

5) Professional transposition function for music and microphone

6) Professional limiter and expander (noise gate) for music and microphone

7) Effect mode, input selection, music volume, microphone volume, effect volume, all can be adjusted remotely

8) The music input channel is equipped with 10-band parametric equalization; the balance type, frequency, Q value, and gain can be finely adjusted

9) The microphone input channel is equipped with 20-band parametric equalization; the balance type, frequency point, Q value, and gain can be finely adjusted

10) Microphone has professional and fine howling frequency shift function with 16 levels adjustable

11) The effect part has echo and reverb effects, which can be used alone or mixed

12) The echo and reverberation of the effect part are provided with 5 bands of parametric equalization, and the equalization type, frequency point, Q value and gain can be finely adjusted.

13) Separate high-pass and low-pass filters for echo and reverb effects

14) All output channels are equipped with 10-band parametric equalization. Equalization type, frequency, Q value, gain can be finely adjusted

15) The main output, center output, subwoofer output, and rear output are equipped with pressure limit and delay functions and mute control.

16) Built-in manager mode and user mode, can store 16 modes

17) This machine can be connected directly via USB free drive and WIFI wireless debugging. Have PC and mobile debugging client.

Application

AR3+ is widely used in fixed-installed entertainment venues such as concert halls, conference halls, multi-function halls, performing arts centers, restaurants hall, high-end bars, KTVs, night clubs and so on.

Remark：

The above packing dimensions, net weight, and gross weight are for reference only. The accurate values are subject to the identification on the batch of products.

L AUDIO reserves the right to make any changes to the product specifications without prior notice. Final specifications to be found in the user manual.
