96KHz sampling frequency, 32-bit DSP processor, 24-bit A/D and D/A conversion
Each function in the device supports individual locking, and a single function can be opened or locked according to site requirements. Prevent misoperation and data confidentiality. Each input and output processing has 6 independent full parametric equalization, and the adjustable gain range can reach ±20dB. At the same time, parametric, high-key, low-key, 1st-order all-pass, 2nd-order all-pass can also be selected. 5 kinds of equalization modes; all have delay and phase control and mute settings, the delay can be up to 1000ms, the delay unit can be selected from milliseconds (ms), meters (m), feet (ft), and the delay can be Adjustment with coarse and fine adjustment modes
The device software has a built-in central control code generator, which can realize one-click switching between Chinese and English
It can be connected to the computer through the external UTWR1 box, which can realize remote control over the Internet 4-way balanced signal input, 8-way balanced signal output; flexible combination of various frequency division modes, high and low-pass frequency division points are available Up to 20Hz～20KHz
It is very convenient, intuitive and concise to directly use the function keys and pulleys on the panel to set the function or connect to the computer to control it through the PC control software; RS485 interface can cascade 250 devices to set ID for control
Adjustable noise gate for each input channel, and each input channel has two full-parameter adjustable dynamic equalization (DEQ), automatic gain control
The output channel can also independently control compression, limiting and freely select the input signal channel, and can copy all parameters of a channel to another channel for simultaneous control
2×24 LCD blue backlight display function settings, 5-segment LED display accurate digital level meter of input/output, mute and editing status
A single machine can store 30 groups of user program data; other data can be stored on other storage media through PC software

Input impedance: balanced 20KΩ
Output impedance: balanced 100Ω
Common analog ratio: >78dB(1KHz)
Input range: ≤+19dBu
Frequency response: 19.7Hz-20KHz(±0.5dB)
Signal to noise ratio: >108dB@1KHz 0dBu
Distortion: ﹤0.002% OUTPUT=0dBu/1KHz
Channel separation: >106dB (1KHz)
Power consumption: ≤25W
Power supply: AC110V/220V 50/60Hz
Product size (W×D×H): 482mm×228mm×44mm
Net weight: 4.3KG
